TECHNICAL SPECIFICATIONS |
| Total
Facility Size: |
292,767
SF Gross |
| Site
Size: |
19.02
Acres
|
| Tenancy: |
Single-tenant corporate facility
|
| Zoning
for Data Centers: |
No
re-zoning required, currently operating data center
|
| Floor
Plates: |
Building
#1:
- Floor “A” 33,352
- Floor “B” 33,512
- Annex Bldg. 11,247
- Floor “C” 34,078
Building #2:
Size - Floor “A1” 42,191
- Floor “A” 47,731
- Floor “B” 48,163
- Floor “C” 42,490
|
| Slab-to-Slab
Heights: |
Building #1:
- Floor “A” to “B” – 19.5’ (Below Grade)
- Floor “B” to “C” – 16.67’
- Floor “C” to Roof – 15’
Building #2:
- Floor “A1” – “A” – 18.5’ (Below Grade)
- Floor “A” – “B” – 16’ (Below Grade)
- Floor “B” – “C” – 16.67’
- Floor “C” – Roof – 15’
|
| Live
Load Capacities: |
Building
#1:
- “A” Floor – Slab on grade
- “B” Floor – 100 lbs/sf
- “C” Floor – 70 lbs/sf except in the EDS area where
it is 100 lbs/sf
Building #2:
- All floors – 150 lbs/sf
|
| Elevation
of lowest floor: |
89’
above 100 year (flood plain) 85’ above 500 year
(flood plain) 4000’ from 500 year flood zone |
| Ground
Water Risk: |
Zero
|
| Access
to highway: |
400
Feet |
| Parking
for autos: |
718 |
| Distance
from active railroad line: |
2.4 Miles |
| Distance
from a nuclear generating station or nuclear waste
storage facility: |
25
Miles to nearest nuclear facility, 50 Miles to second
Nuclear plant |
|
BUILDING FLOOR PLATE |
| Truck
loading docks: |
There
are (2) tailgate landing areas, one in the Annex
|
| Site
perimeter security buffer: |
Along
the southwest edge of the property there is an area
approximately 100 feet long, in which the building
is set back 37 feet. All other areas are in excess
of 50. |
| BUILDING
EXPANSION |
| Availability
Of Contiguous Growth: |
Yes,
at the loss of parking. |
| BUILDING
CONSTRUCTION |
| Material:
|
Concrete,
masonry and steel |
| Number
of stories: |
Building
#1 – 3 stories, one below grade Building #2 – 4
stories, two below grade |
| Utility
Service – Water: |
(2)
4” Domestic water lines, (1) in each building with
an interconnect. (2) 8” fire lines, (1) in each
building All water lines are from the same meter
pit Well – used for emergency only, non-potable |
| Utility
Service – Telephone: |
Verizon
has two separate fiber cables connected to the building
from two different CO’s; GPU Telecom also provides
service, including available dark fibe |
| Utility
Service – Gas: |
None |
| SITE
INFRASTRUCTURE |
| Power
Service Quantity & Type: |
Building
1:
Three (3) 2,000 KVA @ 13,200 V
Building 2: Three (3) 1,500 KVA @ at 13,200
V
Total service is 10.5 MVA.. |
| Utility
Service – Electrical: |
Complex is served by 13.2 KV line #790 from Bern
Church substation. A diversely routed 13.2 KV line
(#791) will be stubbed to curb. 13.2 KV line #793,
from Riverview substation, is adjacent to the property. |
| TELECOMMUNICATIONS |
|
Fiber connection to the FirstEnergy telecom company,
which connects to most major carriers, in addition
to Verizon service. Diverse service to two Verizon
central offices. Dual points of entry, cross-connection. |
| MECHANICAL |
| Cooling
Capacity: |
Building
#1:
- (2) 230 ton Trane units with heat recovery - Standby
cooling – (2) York units
Building #2:
- (3) 250 ton Carrier units and (1) 250 ton Trane
unit, (2) have heat recovery |
| Water
Leak Detection System: |
Yes |
| Back-up
Water Supply for Cooling Towers: |
Yes,
initial backup is the alternate domestic feed and
then the well |
| FIRE
PROTECTION |
| Type
installed: |
Building #1: - Sprinkler in the east wing - Halon
– Data Center, dispatch computer room, storage area
and vault Building #2: - Sprinkler in the general
office area - Halon in the data centers |
| Entire
building covered: |
Building
#1 – No Building #2 - Yes |
| HSSD
Coverage: |
Full coverage |
| SECURITY
SYSTEMS |
| Access
Control: |
Yes |
| Remote
Monitoring: |
Yes |
| EXISTING
RAISED FLOOR |
|
Total
raised floor area: 146,030 Square Feet
Building #1:
- “A” Floor – partial, 8,300sf
- “B” Floor – partial, 3,760sf
- “C” Floor – partial, 6,765sf
18,825 SQ FT TOTAL
Building #2:
- “A1” Floor – partial, 19,825sf
- “A” Floor – entire floor, approx. 42,000sf
- “B” Floor – partial, 23,380sf
- “C” Floor – entire floor, approx. 42,000sf
127,205 SQ FT TOTAL |
| EXISTING
EMERGENCY POWER |
|
Building
#1:
- 1250 KW generator, supports
Building #2:
UPS system which in turn supports various locations
throughout the complex - 80 KW generator,
Life Safety Building #2: - 200 KW generator, life
safety - Switchgear installed for expansion of generator
capacity |
